4×7 Stabilizer bar

Reduces the cushion overhang on the sides from inches to 4 inches.

PARTS:

2 qty – Stabilizer weldments BASE 8-2

4 qty – 3/8-16 x 1 1/2″long hex bolts

4 qty – 3/8″ split washer

4 qty – 3/8″ flat steel washer

1. Remove the leveling foot from the base at this location
2. Thread the leveling foot into this location.
3. Locate the stabilizer tube on the base as shown and use the enclosed bolt with washers in the original threaded holes.
