Mechlok and/or Cable Remove or Release
To Remove the Release Cable:
1. The cable passes through two tabs on the mechlok body.
2. A small screw driver can be used to pry the retaining clip to the side, allowing the cable to exit the hole.
3. Remove the trigger by removing the two screws.
4. Install the new cable by reversing these steps.
To Replace the Mechlok:
1. Follow only steps 1 & 2 above regarding the cable.
2. Note the orientation of the mechlok.
3. Bolt on the new mechlok and reattach the cable.
