FC error code on AC Tech (6/2005-10/2012)
The cause of “FC” is either a bad Speed Pot on the control box or the AC Tech drive went bad.
TEST FOR BAD SPEED POT:
-
Unplug the table
-
Remove the front panel of the control box and disconnect the only 3 wires on the Speed Pot Leave wires connected to all other switches.
3. Turn the table on.
