KB Drive Start/Stop Pedal

Add Corded

PARTS & PREP:

54″ of 4-wire cord, 22ga wire

• cut green wire off both ends
• all male connectors on one end of each color

Corded foot pedal with green and red label, green on right

• cut green wire off
• female connectors on 3 wires

Cord clamps with screws (4 each)

Heyco cord restraint (1) Wire ties, 7 1/2″ (3) and 6″ (3) male connectors (2) female connectors (2)

Heyco cord clamp

1. Use the height pedal to raise the table to the highest position and unplug the table.
2. Remove the screws that secure the plastic enclosure to the top frame and pull it away from the frame on the control box side of the table. wires lead to, is mounted on the scissor. that secure it to the steel base.
3. The end of the cord from the new foot pedal can be inserted into the hole of the steel base with about an inch of the black cord inside the base. the cord by wrapping the restraint around the cord and using pliers to squeeze the restraint as it is pushed into the hole.
4. Connect the four foot long gray cord to the foot pedal. Secure the cord with a cable clamp, as shown.
