Adding Length Extensions
BASE
Adding Length Extensions
PARTS LIST:
- Extension weldments (BASE 1-32)
- Base end caps, 2 qty
-
5/16-18 x 1″ long buttonhead bolts, 4 qty (H1864)
1. Remove the 2 original plastic end caps from the steel base.
2. Drill 3/8″ holes at the four locations noted in the diagram below.
3. Insert the new extensions into the ends of the base tubes and secure with the 5/16-18 bolts.
