Replace the Circuit Board

IF YOUR TABLE IS AT ITS LOWEST POSITION & THE HEIGHT FUNCTION DOES NOT WORK:

Since your table is stuck in the down position you will need to access the original board from underneath.

1. Unplug the table
2. Lay the table on its side
3. Refer to the attached P D F to find the colors wires that are highlighted in yellow. These are the wires for getting power into your new board, to the height motor, and to the pedal. Pull the plastic wire connectors only, not the wires themselves, and pull straight away from the board. Refer to the new board to see the type of terminal it is pulling off of.
4. Lay the new board next to the original (because wires are very short) and plug each wire into the designated terminal of the new board, according to the diagram.
5. Keep the table on its side. Make sure the board is not resting on metal and then plug the table in.
6. Keep the table on its side but hold the cushions so they do not drag on the floor as you press the height pedal.
7. When the height is at its maximum U N P LU G the table again.
8. Follow the following instructions to replace the board.
