Add Drop Function to an 8-inch Cushion

KIT-11-001 AIR FLEX

Add Drop Function to an 8-inch Cushion

This kit can only be added if the release frame already has both drop positions in the weldment. Ask customer if the linear bearing is glued in the unused drop position. Kit needs to include the bearing if not.

Parts are identical for Thoracic and Lumbar

Wire diagram WIRE-81

1. Manifold Subassembly:

Small manifold with additional valve position than table has.

2-station (H7160)- If already has 2 drops

3-station (H7512) – If already has 3 drops

Elbow fitting (H6882)

Brass bolt (H1918)

1. Push button for control box (H7521) – insert “lumb” or “thor”
2. Tension knob subassembly:

M 110 threaded rod, 9inch long

Knob (H1784)

1. Steel ball, 5/8″ (H89)
2. Die spring (H791)
3. Rivet (H2724)
4. Lifter subassembly: Weldment FR 11-25A

Rollers (H6034) – 2 qty

Shoulder bolt, 3/8 x 3/8 long (H757) – 2 qty

Shoulder bolt, 3/8 x 1/2 long (H477) – 2 qty Nylock nuts, 5/16-18 (H236) – 2 qty

1. Cylinder subassembly:

Air cylinder (H6887)

Elbow fitting (H6882)

Clevis (H6888)

Shoulder bolt, 1/4 x 1/2 long (H478) Nylock nut, 10-24 (H1152)

1. Drop rod subassembly: M 962 mount plate

Hex bolt, 5/16-18 x 1 long (H3508) Drop rod (H3507)

1. Cushion bolt subassembly: M333 plate – 2 qty

Washer, steel (H72) – 2 qty

Washer, rubber (H1103) – 2 qty

Shoulder bolt, 3/8 x 2 long (H476) – 2 qty

Nylock nuts, 5/16-18 (H236) – 2 qty

1. Air hose, 5/32″ (H6896) – 2 feet

Linear bearing, 5/8″ IF FRAME DO ES NOT HAVE ALREADY (H108)
